NovalithIC™ Single Half-Bridge Driver
Summary of Features: Very Nice !! Easy but high performance !!
•Path resistance of max. 12.8 mΩ @ 25°C (typ. 10.0 mΩ @ 25°C)
High side: max. 6.5 mΩ @ 25°C (typ. 5.3 mΩ @ 25°C)
Low side: max. 6.3 mΩ @ 25°C (typ. 4.7mΩ @ 25°C)
•Enhanced switching speed for reduced switching losses
•Capable for high PWM frequency combined with active freewheeling
•Switched mode current limitation for reduced power dissipation in overcurrent
•Current limitation level of 55 A min.
•Status flag diagnosis with current sense capability
•Overtemperature shutdown with latch behavior
•Driver circuit with logic level inputs
•Adjustable slew rates for optimized EMI
•Operation up to 40 V
•Green Product (RoHS compliant)
