Power Tailgate

Power Tailgate
In recent years, power tailgates have been moving from optional to standard equipment. The target requirements for POWER SUPPLIES supply, communication, state sensing, and power saving are becoming increasingly stringent each year. Therefore, integrated design of these functions is a crucial element in achieving a power tailgate module that meets these requirements in the smallest possible space and with low power consumption.
Infineon offers a wide range of optimally integrated products, primarily focusing on microcontrollers suitable for controlling PowerTailgate.
Please consider Infineon's various products for your power tailgate needs.

Check out our featured products here.


Circuit diagram explanation

Circuit diagram explanation
The basic circuit of a power tail gate includes a microcontroller, POWER SUPPLIES, communication IC (CAN, LIN), motor drive circuit to operate the opening and closing motor, and position detection sensors. POWER SUPPLIES and communication ICs can be selected according to customer requirements, either as an SBC (System Base Chip) with integrated functions on a single chip, or as individual ICs. Furthermore, for the MOS-integrated driver IC for motor drive, we offer MOS+driver solutions depending on the required current value. (Click here for details)

Download materials

We have compiled various documents below regarding microcontrollers, POWER SUPPLIES, communication ICs (CAN, LIN), motor drive ICs for operating the opening and closing motors, and other components that can be used with the Power Tailgate system. Please take a look.
For further details, please Inquiry NEXTY Advanced Technology Company.




・System Basis Chips (SBC) ・Multi MOS FETS Driver ・Single Half bridge ICs (NovalithIC)
