MAX22216: Quad Smart Serial Controlled Solenoid and Motor Driver with Advanced Diagnostic Features | NEXTY Electronics, Electronic Components and Semiconductor Trading Company

The MAX22216/MAX22217 incorporates four programmable 36V half-bridges. They are primarily intended for driving inductive loads such as solenoid on/off valves, DC motors, proportional valves, bistable valves, and relays. The MAX22216 can supply up to 3.2 AFS per half-bridge, while the MAX22217 can supply up to 1 AFS per half-bridge. The MAX22216/MAX22217 operate in ambient temperatures from -40°C to +125°C.
The MAX22216/MAX22217 half-bridge supports two use cases. The first use case allows configuration settings to be entered via the Serial Peripheral Interface (SPI), and these settings can be changed at any time. The second use case allows settings to be saved in a one-time programmable (OTP) register and loaded at startup. This enables standalone operation. The register is user-configurable. The OTP writing procedure should be performed in a factory where temperature and voltage conditions are properly controlled.
High-side/low-side single-ended drive configurations and bridged-load (BTL) configurations are supported. Furthermore, channel parallelization is supported, as well as voltage-controlled, current-controlled, and hybrid control schemes.
In voltage-driven regulation mode (VDR mode), the half-bridge output voltage is controlled, and POWER SUPPLIES fluctuations are compensated internally.
In current-driven regulation mode (CDR mode), the half-bridge output current is controlled. The current is detected internally and fed back to the controller for precise closed-loop regulation. Furthermore, steady-state errors and dynamic performance can be optimized by setting proportional and integral gains.

Features

It incorporates four serially controlled 36V half-bridges.

1.7A DC (TA = 25°C) and 3.2A full-scale current capability
RON is small and highly efficient
High flexibility:

Independent channel settings
Supports high-side/low-side/bridged load configurations/parallel mode.
Advanced control methods

Voltage/current drive regulation
Two-level sequencer for power saving
DC motor drive with current limiter
Dithering function
Lamp Up/Lamp Down Control
Demagnetization voltage control
Built-in current detection function
Diagnostic function

Measurement of reaction time and operating time
Plunger motion detection
Detection of open load
INDUCTORS Measurement
Digital current detection monitor
Full set of protection features

Overcurrent protection
Overheat Protection
Low voltage lockout
